$625 + GST

Model: i21

 2 SIP accounts, Waterproof, Anti-tamper,  Noise and PoE

SIP:Designing in the most popular communication standard protocol – SIP, you needn’t worry about compatibility, vendor selection and alteration any more.
HD Voice:Wonderful aural enjoying with wideband G.722 coding.
Anti-tamper:Alarming as long as the cover aparts from the housing, meanwhile, reporting to the control center.
Security linkage:Two short-circuit input interfaces and two short-circuit output interfaces, safe isolation circuits designed to prevent miss connections.

Product Specification

Generic
2 SIP Lines
PoE enabled(Power over Ethernet)
Full-duplex speakerphone
Intelligent DSS Keys (Speed dial)
Wall-mount installation
Special integrated noise reducation module
Omnidirectional voice pickup
2 embedded short-circuit input interfaces
2 embedded short-circuit output interfaces.
Support 4 controlled events: remote DTMF;
remote server’s commands; interaction with
short circuit input; talking status
Output interface for active speaker
Audio record output interface
External Power Supply
Multicast
All in ONE: door access, intercom and
paging service
Industrial standard certifications: IP65, IK10,
CE/FCCall Features
Intercom
Speed dial(speed dial key)
Auto-answering (per line)
Voice message (on server)
Local 3-way ConferencePhone Features
Call log (900 entries, in/out/missed)
Programmable DSS keys
Network time synchronization
Action URL / Active URIAudio
Narrowband CODEC: G.711a/u, G.723.1,
G.726-32K, G.729AB
Wideband CODEC: G.722
Full-duplex Acoustic Echo Canceller (AEC) –
Hands- free mode, 96ms tail-length
Voice Activity Detection (VAD) / Comfort Noise
Generation (CNG) / Background Noise
Estimation (BNE) / Noise Reduction (NR)
Packet Loss Concealment (PLC)
Dynamic adaptive jitter buffer up to 300ms
DTMF: In-band, Out-of-Band – DTMF-Relay
(RFC2833) / SIP INFO
Omnidirectional voice pickup: pickup distance
to 5 m

Networking
Physical: RJ45 Ethernet Jacket x2: Network x1
(802.3AF POE Enabled), LAN x1 (Bridged to
Network) IP configuration: Static / DHCP / PPPoE
Network access control: 802.1x
VPN: L2TP (Basic Unencrypted) / OpenVPN
VLAN
QoS

Advanced protection:Strictly follow the high standards of international protection grade, waterproof to IP65, anti-collision reaches IK10.
Noise Reduction:Specific processing module for environmental noise reduction. Meanwhile, support long-distance pickup as far as five meters.
Anti-stamp:In-built anti-stamp nets, to prevent malicious damage.
Wide range temperature adaptability:Applicable temperature ranging from -40 to +70 degrees, adapting to all kinds of harsh environments.

Protocols
SIP2.0 over UDP/TCP/TLS
RTP/RTCP/SRTP
STUN
DHCP
802.1x
L2TP (Basic Unencrypted)
OpenVPN
SNTP
FTP/TFTP
HTTP/HTTPS
Tr069

Deployment & Maintenance
Auto-Provisioning via FTP/TFTP
/HTTP/HTTPS/DHCP/TR069/SIP PNP
Web management portal
Web-based packet dump
Configuration backup/restore
Firmware upgrade
Syslog

Physical Specifications
1 or 2 Hands-free keys or DSS Keys (Speed
dial)
Rj45 Ethernet Jacket x2: Network x1 (802.3AF
POE enabled), LAN x1 (Bridged to network)
Main chipset: Broadcom
Passive switch(short-circuit output): normally
open and normally closed highest at 30V/1A
AC/DC
Audio Amplifier: 2.5W
Output interface for active speaker
Audio record output interface
2 embedded short-circuit input interfaces/2
embedded short-circuit output interfaces
Speaker: 2W/4Ω
Cables: CAT5 or better
Power supply:9~16V/1A DC or PoE
Shell material: Aluminum cover and back case
Protection level: IP65 and IK10
Working temperature:-40~70℃
Storage temperature:-40~70℃
Working humidity: 10~90%
Overall dimension: 195x120x39mm (W x H x L)
Package dimensions: 260x165x62mm
(W x H x L)
Package weight: 0.85KG

Product Specification

Download Here
